⚡ Energy Saving
High efficiency operation
🔧 Easy Maintenance
Simple maintenance
🛠 Durable Design
Long service life
Product Short Description (Below Title)
Clean water. Compact size. Complete protection.
The 250L/H 6-Stage RO system delivers pure water with sand filter, carbon filter, softener, and precision filtration — all in a 55kg lightweight frame. Plug & play. CE certified. Perfect for clinics, schools, offices, restaurants, farms, and high hardness well water areas.
Product Highlights
| 💧 Complete 6-Stage Filtration | ⚡ Energy Saving ULP Membrane |
|---|---|
| Sand filter + Carbon filter + Softener + Cartridge filter + RO + Post treatment. Full protection for your water source. | ULP21-4040 low-pressure membrane reduces energy cost. 220V/1.1KW runs on household outlet. |
| 📦 Compact & Lightweight | 🔌 Plug & Play |
|---|---|
| 55kg only · 640×625×1420mm. Two people can carry it. No forklift needed. Fits in any small space. | Pre-assembled on stainless steel frame. Connect water and power. Start within 4 hours. |
| 🛡️ Softener Included | ✅ CE Certified |
|---|---|
| Removes calcium and magnesium. Prevents RO membrane scaling. Extends membrane life by 30-50%. | 1-year warranty. Factory direct from China. OEM customization available. |
Technical Specifications
| Parameter | Value |
|---|---|
| Model | FRO-214-0.25T-06SC |
| Flow Rate | 250 L/H (≈ 6,000 GPD) |
| Desalination Rate | ≥97% |
| Recovery Rate | 50-65% (Adjustable) |
| Membrane | ULP21-4040 × 1 |
| Pre-treatment | PPCotton + Carbon + Cartridge |
| Voltage | 220V / 50Hz (110V/60Hz optional) |
| Power | 1.1 KW |
| Frame | Stainless Steel, Skid-Mounted |
| Dimensions | 640×625×1420 mm |
| Weight | 55 kg |
| Feed Water Source | Well water, groundwater, municipal water |
| Max Feed TDS | ≤ 1500 ppm |
| Max Feed Hardness | ≤ 400 mg/L |
| Warranty | 1 Year |
| Certification | CE |
6-Stage Filtration Process
Raw Water → Sand Filter → Carbon Filter → Softener → Cartridge Filter → High Pressure Pump → RO Membrane → Pure Water
| Stage | Component | Function |
|---|---|---|
| 1 | Cotton Filter | Removes sediment, rust, suspended solids |
| 2 | Carbon Filter | Removes chlorine, odor, organic matter |
| 3 | Cartridge Filter | 5μm fine filtration, protects RO membrane |
| 4 | RO Membrane | Removes up to 99% of dissolved salts, bacteria, viruses |
| 5 | Pure Water Outlet | Outputs clean, safe drinking water |
What’s Included in the System?
| Component | Qty |
|---|---|
| High Pressure Pump (1.1KW, 220V) | 1 |
| RO Housing (FRP / SS) | 1 |
| RO Membrane (ULP21-4040) | 1 |
| Stainless Steel Frame (304, Skid-Mounted) | 1 |
| PLC Control Panel | 1 |
| Piping & Fittings | 1 set |
| Pressure Gauges & Flow Meters | 1 set |
Note: Raw water tank and pure water tank are not included. They can be purchased separately.
Why This System?
🏭 Built for Small Businesses
Whether you run a small clinic, a school, an office, or a restaurant — this system delivers reliable clean water without taking up too much space.
💧 Perfect for High Hardness Well Water
The built-in water softener removes calcium and magnesium, protecting the RO membrane from scaling. If your water comes from a borehole or well, this is the system you need.
📦 Lightweight & Easy to Install
At just 55kg, two people can move it. No crane. No forklift. Just connect water and power — and you’re running in 4 hours.
🔧 Low Maintenance
PLC auto control with auto flush and low pressure protection. No dedicated operator needed. Just change filters periodically.
Applications
| Industry | Use Case |
|---|---|
| 🏥 Small Clinic | Medical pure water, instrument cleaning |
| 🏫 Small School | Safe drinking water for students |
| 💼 Office | Employee drinking water |
| 🍽️ Restaurant / Cafe | Kitchen water, ice making |
| 🌾 Small Farm | Animal drinking water |
| 🏠 Villa / Home | Whole house water filtration |
| 🌍 Rural / High Hardness Areas | Well water & groundwater treatment |
FAQ
1. Can this system handle well water with high hardness?
Yes. The 6-tank configuration includes a softener specifically designed to remove calcium and magnesium from well water and groundwater.
2. Is it really only 55kg?
Yes. At 55kg, two people can lift and move it. No forklift required.
3. What voltage does it need?
Standard 220V / 50Hz. 110V / 60Hz is available upon request.
4. How long does installation take?
About 4 hours. The system comes pre-assembled — just connect water inlet, drain, and power.
5. Do I need a professional to install it?
No. We provide detailed video tutorials. A general plumber or electrician can handle it.
6. What’s the difference between this and a standard 3-tank RO system?
This system has 3 additional tanks: a softener to remove hardness, plus配套 components. It’s designed specifically for high hardness water sources.
7. What is the MOQ?
1 set. OEM customization available for bulk orders.
8. Do you offer installation support?
Yes. We provide video tutorials and manuals. Remote video guidance is also available.
Ready to Get Clean Water?
💬 Contact us for catalog & best price
