⚡ Energy Saving
High efficiency operation
🔧 Easy Maintenance
Simple maintenance
🛠 Durable Design
Long service life
Product Short Description
Save space. No compromise on quality.
The 250L/H Integrated Sand & Carbon RO system combines sand and carbon filtration into a single tank — saving 40% space. Includes softener, precision filter, and ULP membrane. Perfect for tight spaces like containerized water stations, small mechanical rooms, and outdoor cabinets.
Product Highlights
| 📦 Space-Saving Integrated Design | ⚡ Energy Saving ULP Membrane |
|---|---|
| Sand + Carbon in ONE tank — saves 40% space compared to traditional two-tank systems. Ideal for compact installations. | ULP21-4040 low-pressure membrane reduces energy cost. 220V/1.1KW runs on household outlet. |
| 🔧 Complete 3-Stage Filtration | 🏭 Compact Space适配 |
|---|---|
| Integrated Sand/Carbon + Cartridge filter + RO membrane. Efficient protection for tap water and low TDS well water. | 950×625×1725mm · 125kg. Fits in containerized stations, small mechanical rooms, and outdoor cabinets. |
| 🔌 Plug & Play | ✅ CE Certified |
|---|---|
| Pre-assembled on stainless steel frame. Connect water and power. Start within 4 hours. | 1-year warranty. Factory direct from China. OEM customization available. |
Technical Specifications
| Parameter | Value |
|---|---|
| Model | FRO-214-0.25T-13SC |
| Type | Skid-Mounted RO System with Integrated Sand/Carbon |
| Flow Rate | 250 L/H (≈ 6,000 GPD) |
| Desalination Rate | ≥97% |
| Recovery Rate | 50-65% (Adjustable) |
| Membrane | ULP21-4040 × 1 |
| Tank Configuration | 1 Green Tank (Integrated Sand/Carbon) + 3 Blue Tanks (Softener + Cartridge + RO) |
| Pre-treatment | Integrated Sand/Carbon + Softener + Cartridge |
| Voltage | 220V / 50Hz (110V/60Hz optional) |
| Power | 1.1 KW |
| Frame | Stainless Steel, Skid-Mounted |
| Dimensions | 950×625×1725 mm |
| Weight | 125 kg |
| Feed Water Source | Well water, groundwater, municipal water |
| Max Feed TDS | ≤ 1500 ppm |
| Max Feed Hardness | ≤ 400 mg/L |
| Warranty | 1 Year |
| Certification | CE |
Filtration Process
Raw Water → Integrated Sand/Carbon Tank → Cartridge Filter → High Pressure Pump → RO Membrane → Pure Water
| 1 | Integrated Sand/Carbon | Removes sediment, chlorine, odor — all in ONE tank |
| 2 | Cartridge Filter | 5μm fine filtration, protects RO membrane |
| 3 | RO Membrane | Removes up to 99% of dissolved salts, bacteria, viruses |
What’s Included in the System?
| Integrated Sand/Carbon Tank (FRP with auto valve) | 1 (Green) |
| Cartridge Filter (20 inch) | 1 |
| RO Membrane (ULP21-4040) | 1 |
| High Pressure Pump (1.1KW, 220V) | 1 |
| Stainless Steel Frame (304, Skid-Mounted) | 1 |
| PLC Control Panel | 1 |
| Piping & Fittings | 1 set |
| Pressure Gauges & Flow Meters | 1 set |
| Brine Tank | 1 |
Note: Raw water tank and pure water tank are not included. They can be purchased separately.
Key Features
Feature 1: Integrated Sand & Carbon — Saves 40% Space
| Feature | Benefit |
|---|---|
| One tank instead of two | Saves 40% floor space |
| Fewer connections | Lower leakage risk |
| Pre-assembled | Faster installation |
Perfect for: Containerized water stations, small mechanical rooms, outdoor cabinets, vehicle-mounted systems.
Feature 2: Complete 4-Tank Configuration with Softener
| Tank | Color | Function |
|---|---|---|
| Integrated Sand/Carbon | Green | Removes sediment, chlorine, odor |
| Softener | Blue | Removes calcium & magnesium |
| Cartridge Filter | Blue | 5μm fine filtration |
| RO Membrane Housing | Blue | Final purification |
Feature 3: 125kg — Stable Yet Portable
- Heavy enough for stable operation
- Light enough for two people to move with a pallet jack
- Compact dimensions: 950×625×1725mm
Feature 4: Built for High Hardness Water
The included softener protects your RO membrane from scaling — essential for well water and groundwater applications.
Applications
| Application | Description |
|---|---|
| 📦 Containerized Water Station | Compact design fits perfectly in shipping containers |
| 🏭 Small Factory | Process water, cleaning water |
| 🏨 Small Hotel | Guest drinking water, kitchen water |
| 🏫 School Restaurant | Safe drinking water for students |
| 🏠 Residential Community | Centralized water supply |
| 🚐 Mobile Water Vehicle | Vehicle-mounted systems |
Space-Saving Comparison
| Comparison | Traditional 2-Tank System | This Integrated System |
|---|---|---|
| Number of pre-treatment tanks | 2 (Sand + Carbon separate) | 1 (Sand + Carbon combined) |
| Floor space | 100% | Save 40% |
| Piping connections | More | Fewer — lower leak risk |
| Installation time | Standard | 30% faster |
FAQ
1. What does “integrated sand & carbon” mean?
The sand and carbon filtration media are combined in ONE tank instead of two separate tanks. This saves 40% floor space without reducing filtration effectiveness.
2. Can this system fit in a shipping container?
Yes. The dimensions 950×625×1725mm fit easily in a standard 20FT container with room for operation and maintenance.
3. Is the softener included?
Yes. The 4-tank configuration includes a softener (one of the blue tanks) to remove hardness and protect the RO membrane.
4. What’s the difference between this and the standard 6-tank model?
This model uses an integrated sand/carbon tank (green) instead of separate sand and carbon tanks, saving space. It has 4 tanks total vs 6 tanks in the standard model.
5. Can it handle well water?
Yes. The integrated sand/carbon filter plus softener makes it ideal for well water and groundwater.
6. What is the MOQ?
1 set. OEM customization available for bulk orders.
